Home All brands 9W/m COB | IP66 | 5 METRE PACK

9W/m COB | IP66 | 5 METRE PACK

BL-LS-COB9-WW-IP66-5M

5 Metre Pack:  9W/m COB (Chip on Board) LED Ribbon contains a mighty 480 LED chips per metre, all covered by a single line of phosphor, providing dot-free continuous illumination. The small 16.66mm cutting length allows for greater accuracy in installation. Encased in a silicone sleeve to provide a rating of IP66 making it suitable for exterior or interior use.

5 Metre Pack includes prefitted Power Feed / End Cap + 2 extra Power Feed / End Cap Connectors to allow on-site cutting.

This product is not suitable for use with our mini-profiles due to the end cap height.

Read more about COB ribbon here.
ADD TO ENQUIRY LIST
LOGIN TO VIEW PRICING
  • Specification
  • Accessories
  • Downloads
WATTS

9W/m

LUMENS

769lm/m

CRI

≥90

BEAM ANGLE

180°

DIMENSIONS

W10mm × H5mm × L5m
(W12.5 × H7mm for connectors)

CUTTING LENGTH

16.66mm

MAX RUN PER POWER FEED

5 metres

MOUNTING

3M adhesive backing (Approved aluminium profile is required)

FEATURES

480 LEDs per metre

WARRANTY

3 years

COB | IP66 Connectors

COB | IP66 Connectors

9W/m COB Ribbon | IP66 | 5m Pack | Specifications pdf Download 9W/m COB Ribbon | IP66 | Installation Guide pdf Download COB Ribbon | IP66 | SDoC pdf Download 9W/m COB Ribbon | IP66 | 3000K | IES IES Download
